#INTEL DESKTOP BOARD DQ67EP SERIAL#
CPU Socket Type LGA 1155 CPU Type Core i7 / i5 / i3 / Pentium (LGA1155) Chipsets Chipset Intel Q67 Memory Number of Memory Slots 2×240pin Memory Standard DDR3 1333/1066 Maximum Memory Supported 16GB Channel Supported Dual Channel Expansion Slots PCI Express 2.0 x16 1 x PCI Express 2.0 x16 Mini Card Slots 1 x Mini PCIe Storage Devices SATA 3Gb/s 2 x SATA 3Gb/s SATA 6Gb/s 2 x SATA 6Gb/s SATA RAID 0/1/5/10 Onboard Video Onboard Video Chipset Supported only by CPU with integrated graphic Onboard Audio Audio Chipset Realtek ALC888S Audio Channels 8 (5.1+2) channels Onboard LAN LAN Chipset Intel 82579LM Max LAN Speed 10/100/1000Mbps Rear Panel Ports Video Ports D-Sub + DVI DisplayPort 1 x DisplayPort USB 3.0 2 x USB 3.0 USB 1.1/2.0 4 x USB 2.0 eSATA 2 x eSATA 3Gb/s Audio Ports 3 Ports Internal I/O Connectors Onboard USB 6 x USB 2.0 Other Connectors Serial port headerMain power connector (2 x 12)System fan headerAlternate front panel power LED headerIntel Fast Call for Help (Intel FCFH) headerLow Pin Count (LPC) Debug connectorChassis intrusion headerProcessor fan headerS/PDIF header Physical Spec Form Factor Mini ITX Dimensions (W x L) 6.7" x 6.7" Power Pin 24 Pin Features Features Experience the eco-friendly Small Form Factor (SFF) desktop platform powered by the 2nd generation Intel Core vPro processor family.Intel Desktop Board DQ67 EP, coupled with the latest Intel Active Management Technology (Intel AMT) 7.0, provides the unprecedented secured and seamless PC remote management in SFF platform, featuring the latest SuperSpeed USB 3.0, SATA 6 Gb/s technologies, and triple graphic port options. This Product Guide gives information about board layout, component installation, BIOS update, and regulatory requirements for Intel Desktop Board DQ67EP. CPU Socket Type LGA 1155 CPU Type Core i7 / i5 / i3 / Pentium (LGA1155) Chipsets Chipset Intel Q67 Memory Number of Memory Slots 2×240pin Memory Standard.
